Large Size Ultra High Pressure CNC Water Jet Cutting Machine for Hard Materials

Overview

Basic Info.

Model NO.	Tk-Trump50-G2060-DY
Certification	CE, ISO 9001
Condition	New
Servo Motor	Yaskawa Servo Motor/Drive
PLC	Omron Touch Screen
Intensifier	USA
Oil Pump	Rexroth Oil Pump
Ball Screw and Huid Linear	Abba/Hiwin
Cutting Accuracy	_+0.03mm
Maxi Working Pressure	380MPa
Maxi Pressure	420MPa
Power	37kw/50HP
Weight	7500kg
Transport Package	Standard Package for Exporting
Specification	2000x6000x200mm
Trademark	TEENKING
Origin	China
HS Code	84565000
Production Capacity	20 Sets Per Month

Product Description

(Components and Technical Description)	Platform type: Gantry typeCut area: 3000x2000mmCut thickness: 200mm
	-Double independent controlled cutting heads with separate Z-beams
	Servo motor and control:YASKAWA® (JAPAN)Absolute coordinate servo motor system
	Ball screws / Linear guides:* HIWIN (TAIWAN Brand)*ROUST (GERMANY Brand)
	Max speed in X&Y axis: 30m/minMax speed in Z axis: 2.5m/minX/Y axis accuracy ≤±0 .05 mm per 300mm
	Tolerance repairing system (patent)Preload stretching force into ball bearings to remove linear backlash against worn out.
Machine structure:	Separate X,Y beam from water capture, no resonance and thermal expansion impact from capture.
Double Numeric Control Abrasive Feeder:	Feed volume adjustable by CNC panelprogrammable by IGEMS-auto reduce volume in cornersave abrasive up to 20%water flow back proofSmoother feeding speed obtain finer cutting result.

High pressure pump:

Technical descriptions:

Intensifier: hydraulic drive / TK assembly (USA) componentsInternal mounted 1.5L attenuator)Hydraulic pump: REXROTH®Motor/Starter: SIEMENS® motor 37kW(50hp) Dual Pressure/ Dump valve: SIEMENS delta-star starterMax generated pressure: 415MPa (60,000psi)Operating pressure: 360MPa (53,000psi) @ single 0.33mm ruby 300MPa @ Double 0.26~0.28mm rubyMax Flow: 3.6L/minPressure mode: High/Low level auto shift

Packaging & Shipping

Company ProfileTEENKING CNC MACHINERY CO.,LTDTEENKING CNC MACHINERY CO.,LIMITED is a Chinese company founded in 2003 with headquarters in Foshan city and a filial in Hong Kong city.As a well-known worldwide producer, TEENKING had CE certificated since 2006, and ISO9001 certificated in 2010, we also passed the reexamine every two years and keep our manufacturing quality in best level.we already owned more than 15 national utility model technology patents, and 3 national invention patents.We are the company who concentrate on developing ultra high-pressure pump & water jet cutting equipment.We are holding the advanced high technology for 5 axis dynamical and 3D Waterjet cutting machine, as well as 6 axis robotic abrasive/pure Waterjet cutting system.We are the company who concentrate on developing ultra high-pressure pump &water jet cutting equipment.We are holding the advanced high technology for 5 axis dynamical and 3D waterjet cutting machine, as well as6 axis robotic abrasive/pure Waterjet cutting system.We are in leading position of designing and manufacturing top quality waterjet cutting equipment in China.TEENKING has created its reputation successively by supplying more than 600 set of top quality waterjet cutting equipments to worldwide users who are locating in more than 60 countries.TEENKING insist in producing excellent quality machine with innovation, and pragmatism, "let TEENKING become a world-trust brand" is always our ambition.
